Hazardous Goods
| |
| |
|
|
Introduction
 |
|
Mega-Pak Limited have
been involved in Hazardous
Goods Packaging for many years, during which time we have obtained the primary
distributorship for the U.K. and Ireland for packaging manufactured by Wellpappe
Ansbach, Germany.
As a company we pride ourselves on being able to give advice on any matters
regarding the packing and shipping of hazardous goods  |
|
UN Approved Fibreboard Cartons
|
[] |
| |
|
|
The following range of UN approved cartons are an off the shelf, general use,
fibreboard packaging case. Their distinctive Orange wax coated board makes them
both water resistant and very durable.
The addition of a 4GV license on the cases will enable our customers to pack
non-tested inner packagings in the cases safe in the knowledge that they will
be meeting all of the requirements of IATA, ADR and IMDG* without additional testing
costs.
All of the cases listed below are available from stock. If you are unsure of
which case would be suitable for your needs please call for assistance |
|
|
| |
|
|
| |
|
4GV |
GP I |
GP II |
GP III |
GHAZ01 |
175 x 155 x 213 |
3Kg |
5Kg |
8Kg |
8Kg |
| GHAZ010 |
175 x 155 x 300 |
3Kg |
5Kg |
7Kg |
7Kg |
| GHAZ02 |
213 x 213 x 223 |
4Kg |
8Kg |
8Kg |
8Kg |
GHAZ03
|
275 x 195 x 300 |
6Kg |
12Kg |
20Kg |
30Kg |
GHAZ04
|
325 x 245 x 300 |
8Kg |
17Kg |
25Kg |
35Kg |
GHAZ05
|
360 x 260 x 300 |
9Kg |
21Kg |
30Kg |
40Kg |
GHAZ06
|
430 x 310 x 300 |
18Kg |
30Kg |
40Kg |
45Kg |
GHAZ07
|
390 x 390 x 430 |
24Kg |
43Kg |
60Kg |
70Kg |
GHAZ08
|
570 x 370 x 430 |
41Kg |
60Kg |
75Kg |
85Kg |
| GHAZ09 |
770 x 570 x 550 |
77Kg |
106Kg |
150Kg |
200Kg |
* Please note that additional packing requirements may be needed depending
on the method of transport. Please refer to the correct legal documentation relating
to the method of transport being used.
UN Approved Plywood Cases (4D)
Plywood packing cases (4D’s) are a heavy duty UN licensed packing cases
ideal for the transportation of heavy hazardous products such as wet and dry batteries
and power cells. The plywood cases come flat packed for easy assembly and storage. |
|
 |
|
|
|
| |
|
PGI |
PGII |
PGIII |
| |
|
|
|
|
| HAZ010D |
980 x 580 x 485mm |
129Kg |
163Kg |
215Kg |
| HAZ011D |
780 x 580 x 485mm |
95Kg |
123Kg |
167Kg |
| HAZ012D |
580 x 480 x 485mm |
59Kg |
77Kg |
103Kg |
| HAZ013D |
580 x 380 x 485mm |
42Kg |
53Kg |
71Kg |
|
UN Approved ‘Superpacks’ (4DV)
UN4DV’s or ‘Superpacks’ as they are sometimes referred to are
for use with items that have not been tested with the standard range 4D plywood
cases. The only disadvantage of using these cases is the low packing weight otherwise
they are ideally suited for shipping untested hazardous goods. |
| |
| |
|
PGI |
| |
|
|
| HAZ010V |
980 x 580 x 485mm |
129Kg |
| HAZ011V |
780 x 580 x 485mm |
95Kg |
| HAZ012V |
580 x 480 x 485mm |
59Kg |
| HAZ013V |
580 x 380 x 485mm |
42Kg |
|
UN licensed plywood cases
For sending large or heavy hazardous goods, such as batteries, we recommend
you use plywood packing cases. These are available from stock in a variety of
sizes and packing weights. They are all UN approved for the transport of hazardous
goods by air, road, rail or sea |
|
 |
|
Made to Measure and bespoke packaging
|
[] |
We also have the ability to source packaging to your exact specification if
our stock items do not meet your needs. This facility is available at remarkably
low cost due to our close connections with Wellpappe Ansbach and the multiple
test facilities they have allied to the strong working relationship they have
with OIV who are the licensing authority in Vienna. One advantage of generating
a license through OIV is that there is no annual renewal fee as is applicable
with some other test facilities within Europe. The annual volume needed to competitively
generate a bespoke licensed pack may well surprise you and we would be happy to
advise on this
|
Labels and Documentation
|
[] |
| |
Mega-Pak Limited can provide a complete labelling and documentation service
for all modes of transport including Air, Sea and Road transport. We stockhold
a comprehensive range of hazardous goods labels that meet the requirements of
ADR and IATA as well as hazardous goods declaration forms. |
|
 |
| |
|
|
The following Dangerous Goods Publications are also available:
- ICAO – Dangerous Goods Technical Instructions
- IATA - Dangerous Goods Regulations
- ADR Manuals
- IMDG Code
- UK Road Regulations
- Infectious Substance shipper manuals
|
|
 |
|
| |
|
| |
|
|
Void fill – Vermiculite
|
[] |
| Expholiated Vermiculite is Mega-Pak’s choice
of absorbent and void fill material for the packing of hazardous goods. Its high
absorbency and resistance to chemicals make it an excellent and safe cushioning
material for the transport of dangerous goods. Please call if you wish to receive
a specification sheet.
Vermiculite is supplied in 110 Litre Bags |
|
 |
|
| |
|
| |
 |
| |
