Stock Cartons



Stock Cartons

Single Wall Cartons

Single wall corrugated board is made from two sheets of paper called ‘liners’ and a corrugated inner medium called the ‘fluting’. When the paper is constructed in this way it gives the corrugated board significantly more strength and rigidity than that of each component layer. This construction forms a set of connected arches, which are well known for there ability to support heavy weights. The air space between the flutes also
Single Wall

gives a degree of insulation that gives excellent protection against temperature variations. The fluting medium can also be varied in thickness; from 1.1mm for ‘E’ flute board up to 4.3mm for ‘A’ flute board.

These cartons are available for light weight products, though the smaller boxes are particularly strong. They are available in a range of sizes, shown in inches and milimetres below


CODE SIZE (in) SIZE (mm)
STO073 6 x 6 x 6 127 x 127 x 127
STO002 9 x 6 x 6 229 x 152 x 152
STO012 9 x 9 x 5 229 x 229 x 127
PRE003 9 x 9 x 9 229 x 229 x 229
STO069 10 x 10 x 10 254 x 524 x 254
STO040 12 x 9 x 21/2 305 x 229 x 63
STO003 12 x 9 x 41/2 305 x 229 x 114
STO019 12 x 9 x 6 305 x 229 x 152
STO004 12 x 9 x 9 305 x 299 x 229
IDE001 12 x 9 x 12 305 x 229 x 305
STO017 12 x 12 x 12 305 x 305 x 305
STO005 18 x 12 x 6 457 x 305 x 152
GINNI04 18 x 12 x 9 457 x 305 x 229
STO006 18 x 12 x 11 457 x 305 x 279
STO007 20 x 14 x 14 508 x 356 x 356
STO008 24 x 18 x 18 610 x 457 x 457


Double Wall Cartons

[top]

Double wall corrugated board has a similar construction to single wall board but has two fluting mediums instead of one, and three liners instead of two. This gives the board additional stacking strength and better puncture resistance. Double wall can still be die-cut, as with single wall, but case dimensions have to be larger to allow for the extra thickness in board.

These cartons are available for medium weight products and in


Double Wall
larger box sizes

CODE SIZE (in) SIZE (mm)
STO010 12 x 9 x 41/2 305 x 229 x 114
STO011 12 x 9 x 9 305 x 229 x 229
STO022 12 x 12 x 12 305 x 305 x 305
STO001 14 x 14 x 14 356 x 356 x 356
BLA006 153/4 x 113/4 x 113/4 400 x 300 x 300
STO013 18 x 12 x 12 457 x 305 x 305
STO018 18 x 18 x 18 457 x 457 x 457
STO023 18 x 18 x 30 457 x 457 x 762
BLA004 193/4 x 153/4 x 153/4 500 x 400 x 400
STO009 24 x 18 x 18 610 x 457 x 457
ST0062 24 x 18 x 24 610 x 457 x 610
STO015 24 x 24 x 24 610 x 610 x 610
STO051 30 x 18 x 18 762 x 457 x 457
BOE010 46 5/8 x 31 x 31 1/2 1185 x 785 x 800
WAS004 48 x 32 x 30 1220 x 800 x 750
STO014 48 x 40 x 311/2 1219 x 1016 x 800


Triple Wall & Heavy Duty Cartons

[top]

Triple wall Corrugated, or Triple Wall as it is sometimes referred as, is a heavy-duty board manufactured from three fluting mediums and four liners. The strength of this board compared to its weight makes it an excellent material for the manufacture of heavy-duty cases for export purposes.

These cartons are available for heavy weight products and in larger box sizes. Please call for available sizes


Triple Wall & Heavy Duty
